The Smart Studio is designed to quickly record samples, capturing one core (up to 1m/3ft) per picture under UV and white lights. It is perfect for both offshore and onshore applications.
The Smart Studio is designed to process a quick record of the samples shooting 1 core per picture under UV and WH lights. Perfect for onsite environment and for data archiving.
Black Box material:
Phenolic resin plywood reinforced with Aluminium profiles
Black Box dimensions & weight:
1400x530x970mm/55.11×20.88×38.18”;
96.5 Kg/ 214.44 lb
Exterior connections:
USB for camera.
Power Supply
Enlightenment:
2xFluorescent lamp -36W 6500K (WL-Day light);
2xFluorescent lamp -36W 5000K (BL-Black light).
Camera resolution:
6016×4016 pixels- 24.3 Megapixels.
Software:
Camera Control Pro 2
USB wire & battery:
3 m long 2.0 USB wire (A/A Male connection);
Power supply:
220 V, 50/60 Hz (conversion available from 110V/50Hz up to 220V/60Hz through an optional supply converter).
Spare parts:
2xFluorescent lamp -36W 6500K (WL-Day light);
2xFluorescent lamp -36W 5000K (BL-Black light);
Objective lens:
Focal length 14-24 mm;
AF f/2.8;
