Reference: IMAG-153

Cuttings Studio Single (WH/UV)

The Cuttings Studio Single is an imaging device to photograph drill cuttings under White Light and Ultraviolet Light (365nm or 254nm). Fully automatized, it delivers in quick time a high-resolution results (11μm per pixel) of one sample. This instrument is completely controlled by an intuitive software including following features:• Programming hardware & defining work sessions,• Controlling camera parameters & profile record (UV/WH),• Live view & Autofocus,• Image stitching & Cropping,• Annotations & Measurement on image,• Complete high quality PDF report & Sample library. The Cuttings Studio Single is easy to move and it fit perfectly inside a mud logging cabin.

Material

Phenolic plywood and Aluminium profiles

Dimensions & weight

610x460x460 mm / 24.02×18.11×18.11 in
31.25Kg/69.44lb

External connections

USB 2.0
IEC C14 10A 250VaC socket

Camera & lens

D750
Resolution: 6016×4016 px – 24.3 Megapixels
Macro 90 mm F/2.8

Power

200 W.

Image resolution

Support with:4x
11µm/pixel

Enlightenment

2 x Fluorescent lamp – 8W 6500K (WL)
2 x Fluorescent lamp – 8W 365nm (UV-365nm)

Laptop Characteristics

15.6 In; i5 processor; 8 Gb RAM

Software

Geofactory Cuttings Studio

Electric power supply

220-230 VaC, 50/60Hz

Electric security and protection

Automatic main switch, differential switch & circuit breaker
UV security relay
